22 • IV-SAM-VXP-1B and IV-SAM-VXS-1B Product Manual — Doc. 9324A
Web Configuration Interface - Main Tab
To enter the system settings, select the gear icon at the top of the web configuration interface.
Camera Settings
Select the Camera tab to view the available camera settings.
Camera Tab
The following camera settings can be configured.
Select Control Protocol
Use the Select Control Protocol drop-down menu to select between Serial or IPcontrol.
Select Control Protocol Setting
Camera COMPort
Use the Camera COMPort drop-down menu to select a COMport within the system for a Serial
camera connection.
NOTE:Ensure that a USB to RS-485 adapter is connected to an available USBport on the
system. This will allow a COM port to be exposed on this drop-down menu.
Select Control Protocol Setting
