Crestron CHV-TSTAT and CHV-THSTAT Thermostats
Slab 1 – Floor Warming Only (Continued)
DEVICE OPTIONS
SETUP: DEVICE OPTS
Network ID:
LCD Contrast
CHV-THSTAT
[v2.0, #D8000000]
2A
5
Select Network ID: Valid entries are 03 to FE
in Hex to match the network ID set for the
thermostat in SIMPL Windows.
LCD Screen Contrast:
1 Lighter through 10 Darker
Displays Model number, Firmware version
and TSID.
SCREEN OPTIONS
SETUP: SCRN OPTIONS
Disp Global Page:
Disp Outdoor Page:
Disp Rem Func Pg1:
Disp Rem Func Pg2:
Reverse SMODE Dir
Y
Y
Y
Y
N
Options seen when VIEW is pressed:
Global Page – Temperature & humidity selection for
entire house (if part of a Cresnet system).
Outdoor Page – Temperature & humidity of the
outside sensor.
Remote Function Page 1, 2 – Allows remote
control of other functions (for example: lights,
alarms, etc.).
Reverse SMODE Dir – Allows arrow keys to select
mode functions in both directions.
DISPLAY OPTIONS
SETUP: DISP OPTIONS
Temperature Units:
Temp Display Offset:
Main Scn Lwr Obj:
Use 0.5 Deg C Step:
F
0
0
SB
Y
°F or °C – Display in Fahrenheit or Celsius.
Offset (-6 to +6°F) Allows the user to adjust
the displayed/regulated temperature.
Main Screen Lower Object
SB – Slab OD – Outdoor
HM – Humidity NA – None
°C may be displayed in 0.5 units
Continued on the following page.
