Cristec YPOWER+ - Indicators

44
3.7 INDICATORS
The following LED indicators are visible on the front of the appliance to show the status of the charger.
When the charger saves a new configuration, the status LEDs light up one after the other to indicate that the
configuration has been saved.
Led
Mode
LED status
Charger status
LED "ON"
charging
Charger is ON
Mode stand-by (see section 3.4.3)
default
(off)
No or poor-quality AC current
Input fuse is blown
Internal charger malfunction
LED
ALARM
default
Other faults
LEDS
OPTIONS
Boost
Boost activated
Refresh
Refresh activated
LEDS
BATTERY SELECOR
AGM-GEL…
Battery type: AGM/Gel/ Sealed Lead
Wet lead Battery type: Wet lead
Lithium Battery type: Lithium
Custom Custom mode
LEDS
CHARGE STATUS
-
Charger in BOOST phase
Charger in ABSORPTION phase
Charger in FLOATING phase
Charger in REFRESH phase
(off)
Output voltage OFF
OTD fault
Output fuse blown
temperature range
No output voltage
