Cristec YPOWER+ - Setting the Charger with Bluetooth

35
3.3.1.1 change battery type
Configuration according to 12V or 24V battery type
Description of the battery
type
Floating
voltage
12V/24V
Boost voltage
12V/24V
Maximum
duration of
BOOST at
+/- 5% T
BOOST
Maximum
duration of
ABSOPTION at
+/- 5% T
ABS
FACTORY SETTING (by default)
AGM / GEL/ Sealed lead
Classic sealed type
(Sealed lead)
13.8V/27.6V 14.4V/28.8V 2H 4H
Wet lead
Opened type bat
free electrolyte
13.4V/26.8V 14.1V/28.2V 2H 4H
Lithium
(LiFePO4) with BMS (***)
13.8V/27.6V 14.4V/28.8V 6H 1H
Custom
Via Bluetooth
(*) Voltage on + BAT 1, + BAT 2 and + BAT E with 10% of the rated current and a tolerance of +/- 1%.
The voltages values must be doubled for 24V batteries.
(
**
)
REFRESH is not advised for certain types of AGM batteries
(***) Battery Management System
3.3.1.2 Boost and Refresh mode
- The BOOST function enables faster recharging of the batteries.
- The REFRESH function applies a voltage step periodically to maintain and equalize the battery, thus
preventing sulphation. (see chapter 3.6).
3.3.2 Setting the charger with Bluetooth
The Cristec Connect Bluetooth application is available on the Apple Store and Play Store,
enabling remote wireless connection to the device, as well as device supervision and
configuration. The complete application manual is available on our website:
www.cristec.fr
BOOST mode REFRESH mode
OFF
OFF
FACTORY SETTING (by default)
ON
OFF
OFF
ON
ON
ON
