5 TECHNICAL SPECIFICATIONS
12V-20A, 12V-30A, 24V-15A
Part Number
YPO12-20STPL/(OEPL)
YPO12-30STPL/(OEPL)
YPO24-15STPL/(OEPL)
Model
12V/20A
12V/30A
24V/15A
Recommended battery bank*
100-200Ah
200-300Ah
100-200Ah
Input
Voltage
from 90 to 265VAC single-phase automatic
Frequency
from 47 to 65Hz automatic
Input current consumption 230/115VAC
1,3/2,6A
2/4A
2/4A
Recommended power for a generator
450W
650W
650W
Power factor
1
Efficiency
92.8% in 240V and 91% in 120VAC
Input fuses
T6.3A/250V - SCHURTER Ref. 0001.1032
Output
Number of battery banks
3 separate positive terminals: +BAT E, +BAT 1 et +BAT 2 (integrated Mosfet splitter)
1 -BAT negative terminal
Each bank can be used individually and delivers the rated current
Nominal current (+/-7%) / Rated Power
20A/276W
30A/414W
15A/414W
Charging curve
IU or IUoU through internal push-button, Bluetooth or CAN-Bus
(Boost, Absorption, Floating and Refresh)
Battery type
Lead sealed, Gel, AGM as factory setting , calcium lead, LiFePO4, DC power-supply mode, etc.
Specific request on demand
Boost voltage 14.4VDC for lead sealed battery (factory setting)
28.8VDC for lead sealed battery
(factory setting)
Floating voltage 13.8VDC for lead sealed battery (factory setting)
27.6VDC for lead sealed battery
(factory setting)
Peak to peak ripple and noise < 2% (at rated conditions)
Automotive output fuse mounted in series
in minus pole -BAT
1 x 30A/32V 2 x 30A/32V 1 x 20A/32V
Environment
Cooling
Fanless
Sound level
0 dB
Operating temperature at 230VAC
From -20°C to +60°C (-4°F to 140°F) , derating above 40°C (104°F). See chapter 3.8
Storage temperature
From -20°C to +70°C (-4°F to 158°F)
Relative humidity
up to 70% (95% without condensation)
Casing
Material
Casing comprises 3 parts: Aluminium sink frame / Thermoplastic body / Aluminium clasp
Dimensions (length, height, depth) / Weight
238 x 180 x 81 mm (9.4 x 7.1 x 3.2 in) / 1,9kg ( 2.2 lb)
Fixing centre distance 219 x 155 mm (8.6 x 6.1 in)
Fixing screw (wall)
4 x M5 round head screws
Protection factor
IP22
Standards
CE declaration of conformity
Available on request
CE / EMC MARK
EN61204-3
CE / Security MARK
EN60335-2-29, ISO8846
Protections
- Against transient input overvoltage by varistor (out of warranty)
- Against output polarity inversions by fuse
- Against short-circuits and output overloads
- Against abnormal overheating
Communication
CANBUS (according to models) / Bluetooth as standard (optional on OE version)
Bluetooth BLE +9dBm (2412-2484Mhz)
Options
Temperature probe / Bluetooth dongle (OE versions)/OTD probe/Remote switch
*Recommended battery capacity for lead type batteries, ratio C/10. Consult us for lithium batteries capacity
