4.5.16 Through the pressure window
  
4.5.18 Plate chads disposal connecon
4.5.19 For other oponal device connecons, please refer to Chapter 6
4.5.17 Coolant observaon window
Chapter 4: Offloading, Unboxing and Installing
4.5.15 Li up the rear plate conveyor bridge, adjust and align it against the processor
you can obtain current drum vacuum pressure value and the pressure sensor output status;
Current device coolant volume can be observed through the observaon window. If the coolant level found low,
please add it in me
Chads disposal outlet is located at the CTP device's boom le chassis, please place the chads collector to
the exact posion according to the label indicated as below
