Page 47
Step 1 - Dial Ph # 1.
Step 2 - If not Kissed-off (defined by the 9) continue to next step
Step 3 - Dial Ph # 2
Step 4 - If not Kissed-off (defined by the 9) continue to next step
Step 5 - If not kissed-off return to Ph #1 (the 7 causes a return to the start)
This process is repeated until kissed-off or the maximum number of dialling attempts have been reached for this
scenario.
Example 2 (dual reporting) 172 7
In this example we have defined a scenario with four steps as follows.
Step 1 - Dial Ph # 1.
Step 2 - If not Kissed-off return to Ph # 1 (the 7 causes a return to the start). When
kissed-off or the maximum re-tries reached, move forward to the next step.
Step 3 - Dial Ph # 2
Step 4 - If not kissed-off return to Ph # 2 (the 7 causes a return to the start). When
kissed-off or the maximum re-tries reached, move forward to the next step. If no
further steps, stop.
The first step must be completed i.e. kissed-off or the maximum re-tries reached, before the panel can move past the
first “7”, then it can step forward and execute additional instructions up to the next 7. When the format is Contact ID
or 4+2 the use of the two sevens in the scenario forces the panel to report the same signal to both numbers (Dual
reporting).
MAXIMUM DIAL ATTEMPTS PER SCENARIO NUMBER
P325E Maximum dialling attempts for Scenario # 1-Value 1-99 (Default=10)
P326E Maximum dialling attempts for Scenario # 2-Value 1-99 (Default=10)
P327E Maximum dialling attempts for Scenario # 3-Value 1-99 (Default=10)
P328E Maximum dialling attempts for Scenario # 4-Value 1-99 (Default=10)
TELEPHONE NUMBER PREFIX
P330E 1-16E Telephone Number Prefix - 16 Characters Maximum (Pauses and special characters allowed)
This Prefix can be added to the beginning of any of the 6 telephone numbers by turning on option 6 at addresses
P343E-P348E.
PROGRAM TELEPHONE NUMBERS - P331E - P336E
There are 16 characters available in each of the telephone numbers including five special characters. To program the
special characters that include dialling pauses, the * and # characters, etc, refer to the table below.
P331E 1-16E Telephone Number 1 - where options 1-16 represent up to 16 digits
P332E 1-16E Telephone Number 2 - where options 1-16 represent up to 16 digits
P333E 1-16E Telephone Number 3 - where options 1-16 represent up to 16 digits
P334E 1-16E Telephone Number 4 - where options 1-16 represent up to 16 digits
P335E 1-16E Telephone Number 5 - where options 1-16 represent up to 16 digits
P336E 1-16E Telephone Number 6 - where options 1-16 represent up to 16 digits
Character LED KP Button
Displayed as
On 8LED KP
Displayed as
On 16LED KP
Displayed as
On Alert KP
LCD KP Button
Displayed as
On LCD KP
2.5 sec pause
CONTROL Control 13 Trouble “Control” ”2” -
* Character
MEMORY Memory 12 System “Control” ”3” *
# Character
PANIC Line 11 Ready “Control” ”4” #
Wait for 2nd
ARM Armed 14 Ready/System “Control” ”5” W
5 sec pause
STAY Bypass 15 Ready/Trouble “Control” ”6” =
