CS Instruments FA 550 User Manual

Electrical wiring
Page 14 FA 550 V1.00
9.3.4 Modbus TCP (Ethernet) Optional PoE
M12 x-coded
Data LINES: 1,2 und 3,4
PoE LINES: 5,6 und 7,8
2
8
1
3
5 4
6
7
M12 x 1
Connection cable: Cat 6.
*PoE: Power over Ethernet
9.3.5 Pulse Output
Pulse
X1
X2
X4
1
2
GND
VB+
1 2
3
Mod(A)
1 2 3 4
Pulse
DIR
Main Board
Mod(B)
Potentialfreier
Schaltkontakt
Max. 48Vdc , 500mA
1
2
I (4...20mA)
X3
Remark: The sensor must be connected only in strain less state.
