Operation
Page 33 FA 550 V1.00
Settings 4-20mA  Channel 1  Scale 4mA
Settings 4-20mA  Channel 1 Scale
20mA
„Scale 4mA“ and „Scale 20mA“ allows
defining the desired scaling.
With button „“ select the menu „Scale 4mA“
or „Scale 20mA“ and open it with „OK“
Input is analogous to that described above,
using the „CLR“ the complete entry will be
deleted.
Takeover the inputs/changes with „Save“, or
discard the changes with „Cancel“.
Leaving menu with „back“
