Dimensions
VA 550 English V1.21 Page 20 of 53
5 Dimensions
5.1 Dimension VA 550
Sensor lenght
H [mm]
Scaling [mm]
C1
441
220
C2
521
300
C3
621
400
C4
721
500
C5
821
600
C7
381
160
132 Standard
138 Ex Version
