CTC Union GSW-3424M User Manual

Chapter 6. Manage / Configure the Switch
103
6. Tx Timeout Period:
This is the timeout value for the identification request from the switch to users. The request will be re-tried until
the Re-authentication Max Count is met. After that, authentication fail message will be sent. The valid value is
0~65535.
7. Guest VLAN:
This function will put those users who are authenticated fail in 802.1x operation to a “Guest VLAN”. The Guest
VLAN could be selected here.
8. Dynamic VLAN:
This function will assign user to a VLAN that are indicated by RADIUS Server when 802.1x authentication is pass.
That is, VLAN for users are assigned from RADIUS Server.
[Radius Server Configuration]
This function is for the configuration between switch and RADIUS server. You can assign the IP address of Radius
Server, the protocol port number, and the security key.
[Port Authentication Configuration]
The Port Authentication Configuration is used to select the authentication mode for each port of the switch.
1. Auto: This is the normal 802.1x operation mode. The authentication status (authenticated or unauthenticated)
depends on the authentication result of port.
