CTX DZ33I - Mounting Single Oven onto Base

8
16
21422-0001
WASHER, LOCK SPLIT 3/8” ZP
9
16
21416-0001
WASHER, FLAT SS 3/8”
10
16
2000531
SCR, CAP HX HD 3/8”-16X1” NP
Double Oven Stand Parts
Qty,
Part Number
Description
1
1
67880
INSUL, BASE PART A
2
2
67881
INSUL, BASE PART C
3
2
67882
INSUL, BASE PART B
PARTS LISTED ABOVE ARE FROM 69978 KIT, DZ33I INSULATION
4
1
67884
WLDMT. BASE DZ33
5
1
67614
PANEL, TOP
6
4
66948
ASSY. LEG, CASTER
7
4
59156
SCR, SL TRUSS HD SS 10-32X1-1/2”
8
16
21422-0001
WASHER, LOCK SPLIT 3/8” ZP
9
16
21416-0001
WASHER, FLAT SS 3/8”
10
16
2000531
SCR, CAP HX HD 3/8”-16X1” NP
Triple Oven Stand Parts
Item
Qty,
Part Number
Description
1
1
67880
INSUL, BASE PART A
2
2
67881
INSUL, BASE PART C
3
2
67882
INSUL, BASE PART B
PARTS LISTED ABOVE ARE FROM 69978 KIT, DZ33I INSULATION
4
1
67884
WLDMT. BASE DZ33
5
1
67614
PANEL, TOP
6
4
66947
ASSY. LEG, CASTER
7
4
59156
SCR, SL TRUSS HD SS 10-32X1-1/2”
8
16
21422-0001
WASHER, LOCK SPLIT 3/8” ZP
9
16
21416-0001
WASHER, FLAT SS 3/8”
10
16
2000531
SCR, CAP HX HD 3/8”-16X1” NP
Quad Oven Stand Parts
Item
Qty,
Part Number
Description
1
1
67880
INSUL, BASE PART A
2
2
67881
INSUL, BASE PART C
3
2
67882
INSUL, BASE PART B
PARTS LISTED ABOVE ARE FROM 69978 KIT, DZ33I INSULATION
4
1
67884
WLDMT. BASE DZ33
5
1
67614
PANEL, TOP
11
4
58930
CASTER
2. Lay Wldmt. Base (Item 4, Figure 2-1)
upside down on the floor and remove
the protective film from base. Attach the
four Assy. Leg, Caster (Item 5) using 16
SCR, Cap HX HD 3/8”-16X1” NP (Item
10), 16 Washer, Flat SS 3/8” (Item 9),
and 16 Washer, Lock Split 3/8” ZP (Item
8). For Quad screw casters directly into
basepad.
3. Turn the base assembly upright and set
aside. Also set aside 4 SCR, SL Truss
HD SS 10-32X1-1/2” (Item 7), and
Panel, Top (Item 5). The base will be used
to stack oven on, and the top secures to the
top of the oven top oven.
E. Mounting Single Oven onto Base Assembly
1. Cut the bands holding the protective
shipping carton to the skid. Carefully
remove the bands and lift the carton up
off the oven.
2. Cut the bands holding the oven to the
skid.
