D. Model DZ33I, 380V, CE, 3Ph Schematic……………………………..52
SECTION 1 - DESCRIPTION
CTX Series oven is:
• Electrically powered • Conveyorized
• Zone heated by infrared panels • Electronically controlled
CTX Oven Model:
• DZ33I – 31” (787 mm) long cooking chamber with a MenuSelect™ control.
NOTE: “DZ” designation on ovens stands for: “D” = Dual Conveyor, “Z” = Zone Temperature
Control.
DZ33I
Figure 1
This manual must be kept for future reference
Note:
Wiring diagrams are contained in the manual and
are also located in the oven.
