11. AWNING
Click for FIAMMA Awning User Manual
The H16 is fitted with a Fiamma F45 S Awning. For more information on the operation and
maintenance of this awning please read carefully and refer to the respective Fiamma Owner’s
Manuals provided. The handle and tension rafter are stored in the front lower locker area.
Ensure the awning is packed away or secured in heavy weather to avoid damage.
• Periodically check the brackets are firmly attached (especially after the first trip), make
sure the bolts are not loose and that the holding brackets have not shifted.
• To avoid stains, make sure that your awning is completely dry and clean before closing
it. In the event you must close the awning while wet ensure that it is re-opened for
drying within 12 hours.
• Most dirt is superficial and can be removed with clean water and a cloth or a brush. If
the fabric is very dirty, add some light cleaning detergent. Never use aggressive
chemical substances and never clean the fabric with a high-pressure machine.
• Make sure that the awning rolls perfectly in; when it is, the red indicators in the front
profile ends are no longer visible. Before travelling, make sure the awning is closed
correctly. Damaged fabric will not allow the awning to perfectly roll in. Never use the
awning with a damaged canopy.
• FIAMMA recommends not using the awning at a temperature below 0°C.
1. Use the awning handle to unwind the awning. Use the legs 1 metre out to avoid strain
on the awning and caravan wall.
