CUBICON Style Plus-A15 Series User Manual
If the Extruder module gets separated while the filament is inserted inside of the Extruder, it may not be
able to get separated as the filament is hardened inside of the nozzle.
If the unloading (removing a filament from the Extruder) can’t be executed due to the breakdown or other
causes, cut off the filament from the filament inlet of the Extruder and disassemble the Extruder module.
② Turn [OFF](O) the power of the main body of the printer. If you disassemble the Extruder module
while the power is [ON], the printer may break down due to an electric shock.
③ After untightening the cable fixing bolts (2 places) using the
2mm hex key wrench that is supplied as an accessory (1),
remove the Extruder cable fixing block (2), and then pull out the
Extruder cable from the Extruder module (3). Since the cable is
locking type (Locking Type Connector), the cable connector and
the cable would be damaged if it is pulled out forcibly. Unlock it
by pressing the locking device and pull out carefully.
50
