CUDA 2412 - Options Exploded View Parts List

Cuda 2412 • 8.914-384.0 • Rev. 5/12
33
AUTOMATIC PARTS WASHER
OPERATOR’S MANUAL
ITEM PART NO. DESCRIPTION QTY
DETAIL & POWER BRUSH KIT (8.725-245.0):
1 8.712-778.0 Pump -Air Diaphragm 1
2 8.709-117.0 Clamp, Hose, Uni .62-.75 ST 3
 3 8.712-810.0 Regulator-Air1/4"NPT 1
4 9.804-091.0 Brush -Polyflow (Flo-Thru) 1
5 8.712-815.0 Clip -Detail Brush 1
6 8.712-834.0 Drill -Pneumatic Air R-Angle 1
 7 8.712-835.0 Brush-WireCup2-3/4"Dia.,
   1/4"Stem 1
 8 8.712-836.0 Hose-Assembly1/4"x60",
MPT EA End Power Brush 1
 9 8.712-838.0 Pipe-BallValve1/4"3-Way 1
 10 9.802-254.0 Hose,1/4",Push-on,
   FuelLine/Ft 24"
 11 8.706-161.0 Elbow,1/4",Street,90°Galv 1
 12 8.718-813.0 Screw,10-32"x1/2"BH,
SOC, SS 5
 13 8.711-785.0 Hose,3/8"PushOn,/Ft 27.5"
 14 9.804-567.0 Nut,10/32",ESNA 5
15 8.718-959.0 Washer, #10 Flat S/S 2
16 8.915-637.0 Bracket, Power Brush 1
 17 8.714-007.0 Hose-1/4"IDx7/16"OD
   BunaTubing60Duro 40"
 18 8.706-958.0 HoseBarb,1/4"Barbx1/4"
Pipe, 90° 1
 19 8.706-941.0 HoseBarb,1/4"Barbx1/4"Ml
Pipe, Brass 1
 20 8.706-950.0 HoseBarb,3/8"Barbx1/4"Ml
Pipe 2
21 6.390-126.0 Clamp, Hose, .46-.54 St 4
 22 8.714-255.0 Screw-10-24x1/4"SSMSPhil2
 23 8.706-777.0 Nipple,1/4"Close-p/n-3326-4 1
 24 8.712-808.0 Filter-Inlet(MeshBall1/4"NPT
20 x 20 Mesh) Detail Pump 1
 25 9.802-103.0 Bushing,Snap,5/8" 1
 26 8.711-785.0 Hose,3/8"Push-On,/Ft 18.5"
 27 8.718-568.0 Washer,1/4"FlatSSSealing
Rub 3
ITEM PART NO. DESCRIPTION QTY
DETAIL BRUSH KIT (8.725-251.0):
1 8.712-778.0 Pump -Air Diaphragm 1
2 8.709-117.0 Clamp, Hose, Uni .62-.75 ST 3
 3 8.712-810.0 Regulator-Air1/4"NPT 1
4 9.804-091.0 Brush -Polyflow (Flo-Thru) 1
5 8.712-815.0 Clip -Detail Brush 1
 9 8.712-838.0 Pipe-BallValve1/4"3-Way 1
 10 9.802-254.0 Hose,1/4",Push-on,FuelLine
   /Ft 24"
 11 8.706-161.0 Elbow,1/4",Street,90°Galv 1
OPTIONS - EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
DETAIL BRUSH KIT (8.725-251.0 Cont):
 12 8.718-813.0 Screw,10-32"x1/2"BH,
SOC, SS 5
 13 8.711-785.0 Hose,3/8"PushOn,/Ft 27.5"
 14 9.804-567.0 Nut,10/32",ESNA 5
15 8.718-959.0 Washer, #10 Flat S/S 2
 17 8.714-007.0 Hose-1/4"IDx7/16"OD
Buna Tubing 60 Duro 3.33
 18 8.706-958.0 HoseBarb,1/4"Barbx1/4"
Pipe, 90° 1
 19 8.706-941.0 HoseBarb,1/4"Barbx1/4"Ml
Pipe, Brass 1
 20 8.706-950.0 HoseBarb,3/8"Barbx1/4"Ml
Pipe 2
21 6.390-126.0 Clamp, Hose, .46-.54 St 4
 22 8.714-255.0 Screw-10-24x1/4"SSMSPhil2
 23 8.706-777.0 Nipple,1/4"Close-p/n-3326-4 1
 24 8.712-808.0 Filter-Inlet(MeshBall1/4"NPT
20 x 20 Mesh) Detail Pump 1
 25 9.802-103.0 Bushing,Snap,5/8" 1
 26 8.711-785.0 Hose,3/8"Push-On,/Ft 18.5"
 27 8.718-568.0 Washer,1/4"FlatSSSealing
Rub 3
 35 8.706-328.0 Plug,Pipe1/4"NPTGalv. 1
ITEM PART NO. DESCRIPTION QTY
POWER BRUSH OPTION (8.725-258.0):
6 8.712-834.0 Drill -Pneumatic Air R-Angle 1
 7 8.712-835.0 Brush-WireCup2-3/4"Dia.,
   1/4"Stem 1
 12 8.718-813.0 Screw,10-32"x1/2"BH,
SOC, SS 3
 14 9.804-567.0 Nut,10/32",ESNA 3
16 8.915-637.0 Bracket, Power Brush 1
 27 8.718-568.0 Washer,1/4"FlatSSSealing
Rub 3
ITEM PART NO. DESCRIPTION QTY
AUTOFILL OPTION (8.725-261.0):
28 9.802-514.0 Strain Relief, STRT, LQ Tite
3231 Small 2
 29 8.713-149.0 SolenoidValve,1/2"Brass 1
 30 9.802-146.0 Swivel,1/2"MPx3/4"GHF
w/Strainer 1
31 9.802-423.0 Cord, Service, SEO, 16/3, /Ft
   Coleman 48"
32 8.713-768.0 ▲ Connector, Electrical Pin
Male 3
33 8.713-656.0 ▲ Connector, Electrical 3 Pin
Female 1
▲ Not Shown
