10 Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual
Chapter 2 • Introducing the Cummins INLINE™ 7 Data Link Adapter
The following features behave the same whether the device is in Bluetooth
®
or Wi
Feature
What It Does
Vehicle Port Connects the INLINE™ 7 to a vehicle/engine for
power and data.
Power LED
Illuminates when the device receives power.
Vehicle Data LED Illuminates when the device is receiving data from
the vehicle.
Fault LED
Illuminates when a problem is detected.
USB Port Connects the device to your PC (wired
connection).
Latching USB Mini-B Connector for connection to
PC host. Not used
with iOS device.
-Fi mode:
The Wireless LED and the Reset Button, however, behave differently depend-
ing on which mode (i.e., Bluetooth or
Wi-Fi) the device is in.
Feature
What It Does
Wireless Comm LED:
Blue: Bluetooth Mode
If the device is Discoverable:
• Illuminates solid blue when connected.
• Blinks every second when not connected.
If the device is Non-Disc
overable:
• Illuminates blue when connected.
• Off when not connected.
Wireless Comm LED:
White: Wi-Fi—Mini
Access Point Mode
Mini Access Point Mode:
• Illuminates solid white when a client PC
conn
ects to the device.
• Off when no client PC is co
nnected.
