- Device Features
Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual 11
Wireless Comm LED:
Orange: Wi-Fi—Infra-
structure Mode
Infrastructure Mode:
• Stays off when not associated with a
netw
ork Access Point.
• Blinks every second when associated with
an access
point, but no IP address
assigned.
• Illuminates solid orange when successfully
assigned an IP address.
Reset Button
Bluetooth Mode
The INLINE™ 7 factory default is Bluetooth
mode in a Non-Discoverable status. To confirm
that the device is in Bluetooth mode, press the
Reset button momentarily and the Wireless
LED will illuminate blue.
In Bluetooth mode, the Reset button is used to
ch
ange the status of the device. The two status
modes are:
• Non-
Discoverable—When the INLINE™
7 is Non-Discoverable, it will only connect
to a host device with which it has previous-
ly been paired.
• Di
scoverable—When the INLINE™ 7 is
Discoverable, a host device can detect,
pair, or connect to it.
To change the mode from Non-Discoverable to
Disco
verable, press and hold the Reset button
until the Wireless LED begins to flash blue
(about 3 seconds).
Once a connection is established, the LED
tur
ns solid blue. After two minutes, discover-
ability will time out, and the device
will go back
to Non-Discoverable status.
Feature What It Does
