12 Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual
Chapter 2 • Introducing the Cummins INLINE™ 7 Data Link Adapter
Reset Button
Wi-Fi Mode
When using Wi-Fi, the INLINE™ 7 can be con-
figured for either of the following modes:
• Mini-Access Point (Wi-Fi default)
• Infrastructure
Note:
INLINE™ 7 cannot be used in Infrastruc-
ture mode until it has been configured using
the Explorer utility (see U
sing the Cummins
INLINE™ 7 Explorer in Chapter 3 of this
manual).
Once Infrastructure mode has been config-
ured, you can switch between Mini-Access
Point and Infrastructure modes by pressing
and holding the Reset button for three (3)
seconds. The LED will change color to indicate
the mode change.
Reset Button
(to switch modes)
The Reset button is also used to switch back
and forth between Bluetooth and Wi-Fi modes.
To switch modes, press
and hold the Reset
button for about ten (10) seconds. All LEDs will
flash momentarily to indicate that the device
has been reconfigured and reset.
Once the device reboots, the color of the
Wireless
LED will reflect the wireless mode:
• Bl
ue = Bluetooth mode
• Wh
ite = Wi-Fi, Mini Access Point mode
• Ora
nge = Wi-Fi, Infrastructure mode
Feature What It Does
