34 Cummins INLINE™ 7 Data Link Adapter Installation and Setup Manual
Chapter 3 • Installing the Drivers and Setting Up the Device
i Some Bluetooth
®
adapters may require you to configure a Bluetooth
®
environment. If this is necessary, an Initial Bluetooth Configuration Wizard
screen will display at the conclusion of the adapter installation process.
If this happens, use the CD that came with the adapter.
5 Connect the DB26 female end of the appropriate adapter cable to the
INLINE™ 7.
6 Attach the other end of the adapter cable (i.e., the Deutsch connector end) to
the vehicle’s diagnostic connector.
i The vehicle’s diagnostic connector is typically located under the dash-
board on the driver’s side, or beside the driver’s seat. It can also be
lo
cated in the engine compartment, near the electronic control module
(ECM).
—At this point, the Power LED (green) on the INLINE™ 7 should be illumi-
nated (on).
—If the Power LED is
not illuminated, turn the vehicle’s key to the ON posi-
tion, leaving the engine off
7 Pre
ss and hold the Reset Button until the Wireless LED begins to flash blue
(about 3 seconds).
This will put the INLINE™ 7 in Discoverable Mode.
When the INLINE™ 7 is
Discoverable, a host device can detect, pair, or connect to it. Once a con-
nection is established, the LED turns s
olid blue. After two minutes,
discoverability will time out, and the device will go back to Non-Discoverable
status.
i See Device Features in Chapter 2 of this manual for a detailed discussion
of the Reset Button.
8 Move on to Pair the Device, next in this manual.
