1-Slot Data Transport System (CSfC) A - 1 Specifications
© 2024 Curtiss-Wright Defense Solutions Revision 2.0
Specifications
A.1 Envelope / Mounting Dimensions
A.1.1 DZUS Mount
See Figure A.1.
A.1.2 L-Bracket Mount
See Figure A.2.
A.1.3 RMC Module
See Figure A.3.
A.2 DTS1+ CSfC Specifications
Physical Dimensions
Height...................................................................................................... 1.50 In. (38.1 mm) chassis
Width ..................................................................................................... 5.00 In. (127.0 mm) chassis
Depth...................................................................................... 7.99 In. (202.9mm) knob to GND lug.
Weight:
Without RMC Module ............................................................................................. 2.60 lb. (1.18 kg)
Power
Input Power ................................................................................................28 VDC (MIL-STD 704E)
Power Dissipation ....................................................................14 Watts average with RMC module
Peak Inrush Current ........................................................................................................... 1.3 Amps
A.3 RMC Module Specifications
RMC Module Physical Dimensions
Height................................................................................................................. 0.66 In. (16.76 mm)
Width ......................................................................3.000 + 0.22 In.rails (76.20 mm +5.59 mm rails)
Depth..................................................................... 5.000 + 0.390 In. knob (27.0mm +9.9 mm knob)
Weight ..................................................................................................................... 0.7 lb. (0.317kg)
* RMC module weight dependent on configuration. Weight provided is maximum weight for any
RMC module configuration.
Reliability
Data Reliability .<1 non-recoverable error in 10
14
bits read
Data Retention .>10 years
SSD Endurance>100,000 writes
Capacity
256 GB (unformatted) .........................................................................................235 GB (formatted)
1 TB (Unformatted) .............................................................................................931 GB (formatted)
2 TB (Unformatted) .......................................................................................... 1.862 TB (formatted)
4 TB (Unformatted) .......................................................................................... 3,725 TB (formatted)
8 TB (Unformatted) .......................................................................................... 7,496 TB (formatted)
