Curtiss-Wright DTS1+ CSfC - Figure A.1 DZUS Mount

This document in its entirety is subject to export control restrictions on the title page of this document.
User Guide
DDOC0199-000-A9
A - 2 Specification
1-Slot Data Transport System (CSfC)
© 2024 Curtiss-Wright Defense Solutions
Revision 2.0
Specification
Figure A.1 DZUS Mount
DDOC0199-0023
5.75
2X .19 2X .19
1.875
2X .56
2X .56
3X .45
.98
6.50
.51
7.99
1.50
1.04 1.46 1.46 1.04
3X .84
