User Guide DDOC0199-000-A9
1-Slot Data Transport System (CSfC) A - 7 Specifications
© 2024 Curtiss-Wright Defense Solutions Revision 2.0
• Linear 3 seconds from 0g to 5g, remain at 5g for 10 seconds, linear fall back to 0 in 3
seconds. 3 directions
• Operational Shock per MIL-STD-810H, Method 516.8, Procedure I
• 20g peak, 11 ms wide, 3 shocks in each direction per each axis
• Crash Safety per MIL-STD-810H, Method 516.8, Procedure V, Non-operational
• 40g peak, 11 ms wide, 2 shocks in each direction per each axis
• Bench Handling per MIL-STD-810H, Method 516.8, Procedure VI, Pre-Test: Operational, Test:
Non-operational, Post-Test: Operational
• Mold Growth (Fungus) per MIL-STD-810H, Method 508.8, US fungus Test: Non-operational,
operation verified within 8 hours
• Salt Fog (Mist) per MIL-STD-810H, Method 509.7 Procedure I, Pre-Test: Operational, Test:
Non-operational, Post-Test: Operational
• Contamination by Fluids per MIL-STD-810H, Method 504.3 DEF STAN 91-101, DEF STAN
91-87, DIESO 47/20, AVGAS, AL34, Pre-Test: Operational, Test: Non-operational, Post-Test:
Operational
• Blowing Dust per MIL-STD-810H, Method 510.7 Procedure I, Dust Concentration: 2.2 g/cu m,
Velocity: 9.0 m/s, Duration: 3hrs, Temperature +30C, Humidity <30%, Pre-Test: Operational,
Test: Non-operational, Post-Test: Operational
• Ice Formation - Operational per MIL-STD-810H, Method 521.4, -10C, depth 13mm
• Explosion Proofness per MIL-STD-810H, Method 511.7, Procedure I, Operational
• 15,000 feet
• EMI/EMC per MIL-STD-461G
• CE101 - Conducted Emissions, Power Leads, 30 Hz to 10 kHz
• CE102 - Conducted Emissions, Power Leads, 10 kHz to 10 MHz
• RE101- Radiated Emissions, Magnetic Field, 30 Hz to 100 kHz
• RE102 - Radiated Emissions, Electric Fields, 2 MHz to 18 GHz
• CS101 - Conducted Susceptibility, Power Leads, 30 Hz to 150 kHz
• CS114 - Conducted Susceptibility, Bulk Cable Injection, 10 kHz to 200 MHz, Curve 5
• CS115 - Conducted Susceptibility, Bulk Cable Injection, Impulse Excitation
• CS116 - Conducted Susceptibility, Damped Sinusoid Transients, Cables and Power
Leads, 10 kHz to 100 MHz
• RS101 - Radiated Susceptibility, Magnetic Fields, 30 Hz to 100 kHz
• RS103 - Radiated Susceptibility, Electric Fields, 2 MHz to 18 GHz, 200 Volts/meter
• Electrical Power per MIL-STD-704F
• Normal, Aircraft Electrical Operation
• LDC101 Load Measurements
• LDC102 Steady State Limits for Voltage
• LDC103 Voltage Distortion Spectrum
• LDC104 Total Ripple
• LDC105 Normal Voltage Transients
• Transfer, Aircraft Electrical Operation
• LDC201 Power Interrupt Abnormal, Aircraft Electrical Operation
• LDC301 Abnormal Steady State Limits for Voltage
• LDC302 Abnormal Voltage Transients (Overvoltage/Undervoltage)
• Emergency, Aircraft Electrical Operation
• LDC401 Emergency Limits for Voltage Starting, Aircraft Electrical Operation
• LDC501 Starting Voltage Transients
• Power Failure, Aircraft Electrical Operation
• LDC601 Power Failure
• LDC602 Polarity Reversal
• ESD per RTCA/DO-160E, Section 25
• 10 ESD discharges of +15000V and -15000V at each knob or connector (4 places)
Operational
