Figure B.6 Ethernet Lab Cable Wiring Diagram
B.4 Ground Lug
A ground cable is required, but not provided. The ground cable is installed on the DTS1+ CSfC
ground lug E1. The provided nut should be torqued to 18 in. lb. to ensure proper connection.
DDOC0199-0038
213
456
891011
19 18
131415
17
12
16
7
P2
6
5
4
3
2
1
12
11
10
9
8
7
13
19
18
17
16
15
14
C2
B2
A2
D2
ETHERNET
P1
