Curtiss-Wright DTS1+ CSfC - Page 76

User Guide DDOC0199-000-A9
1-Slot Data Transport System (CSfC) 8 - 17 Operation
© 2024 Curtiss-Wright Defense Solutions Revision 2.0
NOTE
Values shown are examples, not actual required readings.
Example
8.8 Built In Test
8.8.1 IBIT (Initiated BIT)
NOTE
Results will be provided as 1 (Pass), 0 (Fail), and NA (function not active)
The ibit command provides a snap-shot of the DTS1+ CSfC status. To view status, type ibit and
press E
NTER key.
• IBIT_MON line provides results for system monitor subsystem.
• IBIT_ETH line provides results for Ethernet subsystem.
• IBIT_RMC# line provides results for RMC module in slot #
Example
8.8.2 MBIT (Maintenance BIT)
The mbit command is used with various options to perform maintenance built-in tests. Several of
these tests either destroy or may destroy data on the RMC module. As a result, to perform these
tests use of a --go option along with command option is required.
cw_dts> sens
[sens]
_______________________________VOLTAGES___________________________
SENSOR VALUE MIN MAX STATUS
V_ETH_0.9
0.89 0.81 0.99 Pass
V_ETH_1.5 1.52 1.35 1.65 Pass
V_ENOV_2.5 2.49 2.25 2.75 Pass
V_ENOV_1.2 1.19 1.08 1.32 Pass
V_MAIN_12V
12.00 10.90 13.20 Pass
V_V5.0 4.89 4.50 5.50 Pass
V_V3.3 3.30 2.98 3.64 Pass
V_RMC0_12 11.87 10.90 13.20 Pass
V_RMC0_5 4.93 4.50 5.50 Pass
V_RMC0_3 3.30 2.98 3.64 Pass
CAP_OK 1 - - Pass
____________________________TEMPERATURES__________________________
SENSOR VALUE MIN MAX STATUS
T_COMF
32 -45 90 Pass
T_COMM 35 -45 90 Pass
T_COMR 29 -45 90 Pass
T_VREG 28 -45 90 Pass
T_PSUT
29 -45 90 Pass
T_PSUB 28 -45 90 Pass
T_RMC0_DR 32 -45 90 Pass
T_RMC0_DF 32 -45 90 Pass
_____________________________HWMON SENSORS________________________
SENSOR VALUE MIN MAX STATUS
CORE0 34 -40 110 Pass
CORE1
34 -40 110 Pass
CORE2 34 -40 110 Pass
CORE3 34 -40 110 Pass
[!sens] OK
cw_dts> ibit
[ibit]
IBIT_MON: mcu=1/0 i2c=1/0 volt=1/0 status=OK/ERR
IBIT_ETH: eth0=1/0 eth1=1/0
IBIT_RMC0: volt=1/0/NA ata=1/0/NA smart=1/0/NA status=OK/ERR
[!ibit] <summary>
