Audio
• Stereo audio (left/right) and microphone
GPIO
• 8 x general-purpose digital I/O
I/O Expansion
• Up to 2x native slots for Mini-PCIe card I/O modules (for optional MIL-STD-1553, ARINC 429,
video frame grabber, additional serial, Ethernet, CAN, USB ports, civilian GPS, or Wi-Fi, etc.) and
1x M.2 slot.
• 55+ spare pins available on circular connectors for expansion I/O signals
• Application engineering services available for pre-integrated I/O modules by the factory
• Multiple headers found on carrier board for additional I/O signals from SOM available internally to
potentially support special customer requirements for CSI MIPI cameras, HDMI, etc.
Operating System
Pre-installed NVIDIA Linux for Tegra (L4T) based on Ubuntu, which supports common APIs and NVIDIA’s
development tool chain (including JetPack Deep AI learning for neural network applications)
Storage
• 1 x eMMC 5.1 Flash on SOM module (32 GB capacity)
• 1 x M.2 (NGFF) SSD, SATA or x1 / x2 PCIe
o M.2 PCI Express or SATA SSD in 2260 / 2280 form factors with 75-position B or B/M key, up
to ~512 GB / 1 TB capacities
• Optional removable 2.5” SATA SSD in add-on mechanical segment (64 GB to ~8 TB capacity)
Mechanical Specifications
Physical
• Weight:
o Base system, exclusive of add-on I/O or storage modules: ~ 2 lb (0.9 kg)
o System with integrated removable storage segment, excluding or I/O modules: ~2.75 lb (1.25
kg)
• Chassis: aluminum alloy, corrosion resistant
• Cooling: fanless, no moving parts, no cold plate required
• Ingress protection: dust and water proof (similar to IP67)
• Finish: black anodize finish per MIL-A-8625, Type II, Class 2
• Connectors: micro-miniature MIL-DTL-38999-like
o Glenair Mighty Mouse 801 Series / Amphenol 2M series connectors with environmental
sealing (50%+ smaller/lighter than traditional 38999s)
• Installation: 4 x mounting holes on flanges
