INTRODUCTION
KPM216H
4
ytilauqhgiH
ces/mm05
lamroN
ces/mm001
deepshgiH
ces/mm521
• Easy paper changing (automatic paper loading).
• Paper width: 210/216 mm (8.5”).
• Bar code UPC-A. UPC-E, EAN13, EAN8, CODE39, ITF, CODABAR, CODE93,
CODE128 and CODE32.
• 3 standard and international character set fonts.
• Definition of function macros for automatic operation re-call.
• Graphic mode printing.
• Print density (-50% to +100%).
• Serial interfaces: RS232 (1200 to 230400 bps)
• Interfaces: RS232-USB and CENTRONICS-RS232.
• Rotating cutter.
• Double function ticket presentation: “ejecting” and “retracting”.
• Sensors: paper end, ticket present, near paper end, virtual paper end.
• Optional 90° paper output.
PRINTER DESCRIPTION
The printer (fig.2) is comprised of a metal frame, printing mechanism, a cutter and an ejector
Located on the keypad are the following keys: LINE FEED (1), FORM FEED (2), Reset (3)
and status LED (4).
• LINE FEED key. When the LINE FEED key is pressed, the printer advances the paper
so that the paper may be inserted in the printing mechanism. During power-up, if the
LINE FEED key is held down, the printer will perform the FONT TEST routine.
• FORM FEED key. When the FORM FEED key is pressed, the printer advances the
paper by a pre-set length. During power-up, if the FORM FEED key is held down, the
printer enters the SETUP routine.
• Reset key, activating through a single-point tool (max diameter 2.5mm). When the Reset
key is pressed, the printer executes an hardware reset such as the power shut off/
power on.
• STATUS LED displays printer hardware status. In case of malfunction, the color and
flash frequency changing as follows:
