1. INSTALLATION AND USE
KPM216H
11-
4
6
1
3
1.1 CONNECTIONS
1.1.1 Power Supply
The printer is equipped with an external power supply outlet (see Fig. 1.1). The connector pin
configuration is as follows:
Model no. type : Header : Molex 39-30-0060 (Vertical)
Housing: Molex 39-01-2065
.oNniPlangiS
1
V42+
2
V42+
3
V42+
4
DNG
5
DNG
6
DNG
WARNING:
Respect power supply polarity.
(Fig.1.1)
(Tab.1.1)
