1. INSTALLATION AND USE
KPM216H
41-
(Fig.1.5)
KPM216H-U MODEL
1.4 CONFIGURATION
This printer permits the configuration of default parameters. The printer’s configurable
parameters are:
• RS232 Baud Rate: 230400, 115200, 57600, 38400, 19200
D
, 9600, 4800, 2400,1200.
• RS232 Data length: 7, 8
D
bits/char.
• RS232 Parity: None
D
, Even or Odd.
• RS232 Handshaking: XON/XOFF
D
or Hardware.
• Busy condition : RxFull
D
o OffLine/RxFull
(2)
.
* PRINTER SETUP *
INTERFACE ................................. RS232,
USB
PROGRAM MEMORY TEST........ OK
DYNAMIC RAM TEST .................OK
EEPROM TEST ........................... OK
CUTTER TEST ............................ OK
HEAD VOLTAGE [V] = 24.28
HEAD TEMPERATURE [°C] = 24
PWM EJECTER [%] = 67.1
PAPER PRINTED [cm] = 4970
CUT COUNTER = 256
RETRACT COUNTER = 0
POWER ON COUNTER = 55
RS232 Baud Rate : 115200 bps
RS232 Data length : 8 bits/chr
RS232 Parity : None
RS232 Handshaking : Xon/Xoff
Busy Condition : RxFull
USB Address Number : 0
USB Status Monitor : Disabled
Autofeed : CR disabled
Print Mode : Normal
Chars / inch : A=11 B=15 cpi
Speed / Quality : Normal
Automatic Ejecting : Disabled
Paper Retracting : Disabled
Dot Damage Prevention : Disabled
Notch Alignment : Disabled
Short ticket (< 150mm) : Disabled
Print Density : 0%
[FF] Key to enter setup
[LF] Key to skip setup
(Fig.1.6)
KPM216H-P MODEL
* PRINTER SETUP *
INTERFACE .............................RS232/
CENTRONICS
PROGRAM MEMORY TEST........ OK
DYNAMIC RAM TEST .................OK
EEPROM TEST ........................... OK
CUTTER TEST ............................ OK
HEAD VOLTAGE [V] = 24.28
HEAD TEMPERATURE [°C] = 24
PWM EJECTER [%] = 67.1
PAPER PRINTED [cm] = 4970
CUT COUNTER = 256
RETRACT COUNTER = 0
POWER ON COUNTER = 55
RS232 Baud Rate : 115200 bps
RS232 Data length : 8 bits/chr
RS232 Parity : None
RS232 Handshaking : Xon/Xoff
Busy Condition : RxFull
Autofeed : CR disabled
Print Mode : Normal
Chars / inch : A=11 B=15 cpi
Speed / Quality : Normal
Automatic Ejecting : Disabled
Paper Retracting : Disabled
Dot Damage Prevention : Disabled
Notch Alignment : Disabled
Short ticket (<150mm) : Disabled
Print Density : 0%
[FF] Key to enter setup
[LF] Key to skip setup
