5.4 Printer parameters
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the printer has been turned off and they are stored in non-volatile memory.
RS232 BAUD RATE Communication speed of the serial interface:
1200 9600 57600
2400 19200
D
115200
4800 38400
RS232 DATA LENGTH Number of bit used for characters encoding:
7 bits/char
8 bits/char
D
RS232 PARITY Bit for the parity control of the serial interface:
None
D
= parity bit omitted
Even = even value for parity bit
Odd = odd value for parity bit
RS232 HANDSHAKING Handshaking:
XON/XOFF
D
= software handshaking
Hardware = hardware handshaking (CTS/RTS)
BUSY CONDITION Activation mode for Busy signal:
RXFull
D
= Busy signal is activated when the buffer is full
OffLine/ RXFull = Busy signal is activated when the printer is both in OffLine status and
the buffer is full
signal is activated when the printer is both in Off Line status and the buffer is full or only if the reception buffer is full.
USB ADDRESS NUMBER
than a USB device connected with the same PC):
0
D
3 6 9
1 4 7
2 5 8
NOTE: This parameter is used to identify univocally the USB printer by a numerical address code, if on the PC
are connected two printers that are the same models.
AUTOFEED Setting of the Carriage Return character:
CR disabled
D
= Carriage Return disabled
CR enabled = Carriage Return enabled
45
