10.3 Alignment parameters


“Notch/Distance” value varies from 0mm minimum and 32mm maximum.
If the “Notch Distance” value is set to 0, the alignment point is set at the beginning of the black mark.
PRINTING DIRECTION
Alignment
point:
notch front
0
“Notch Distance”
Alignment
point
80
