Cyber Controller User Manual

5. OPERATION
5.3.6 CAMERA SETUP
Set up Camera ID Range, the Protocol , Baud Rate of the Camera, and Output Port.
You can select Individual Setup or Whole Setup. Navigate the Cursor by pushing the joy stick up or
down. Cursor moves to the desired position.
○
1
CAM ID Setting: You can select the camera ID which you need to choose from CAM ID to CAM ID.
Input the Camera ID number
and Press ENT
20
Push the joystick right.
○
2
COMMUNICATION PROTOCOL Setting: In the Camera ID Range, You should choose the
Communication Protocol. To navigate and choose the communication protocol, push the joystick
left/right or twist the joy stick clockwise/counterclockwise.
Push the joystick left/right
or twist the joystick
clockwise/counterclockwise.
○
3
BAUD RATE Setting: In the Camera ID Range, You need to decide the Baud Rate.
To navigate and choose the Baud Rate, push the joystick left/right or twist the joy stick
clockwise/counterclockwise.
Push the joystick left/right
or twist the joystick
clockwise/counterclockwise.
Protocol
CYBER SCAN I
CYBER SCAN II
P-D TYPE
P-P TYPE
S-D DOME
BAUD RATE
2400 BPS
4800 BPS
9600 BPS
38400 BPS
→ CAM ID:[001 – 001] → CAM ID:[999 -– 999]
COMM.:CYBER SCAN I COMM.:CYBER SCAN I
BAUD :9600 BPS BAUD :9600 BPS
PORT :RS-485 PORT :RS-485
CAM ID:[999 – 999]
→COMM.:CYBER SCAN I
BAUD :9600 BPS
PORT :RS-485
CAM ID:[999 – 999]
COMM.:CYBER SCAN I
→BAUD :9600 BPS
PORT :RS-485
