Cyber Controller User Manual

5. OPERATION
5.3.7 DVR SETUP
Set up DVR ID Range, the Protocol , Baud Rate of the DVR, and Output Port.
You can select Individual Setup or Whole Setup. Navigate the Cursor by pushing the joy stick up or
down. Cursor moves to the desired position.
○
1
DVR ID Setting : You can select the DVR ID which you want to set from DVR ID to DVR ID.
Input the Camera ID number
and Press ENT
22
→ DVR ID:[001 – 001] → DVR ID:[255 -– 255]
Push the joystick right.
COMM.:ENBEDDED DVR COMM.: ENBEDDED DVR
BAUD :9600 BPS BAUD :9600 BPS
PORT :RS-485 PORT :RS-485
○
2
COMMUNICATION PROTOCOL Setting : There is only Embedded DVR protocol.
DVR ID:[255 – 255]
→COMM.:EMBEDDED DVR
BAUD :9600 BPS
PORT :RS-485
○
3
BAUD RATE Setting : In the DVR ID Range, You need to decide the baud rate.
To navigate and choose the baud rate, push the joystick left/right or twist the joy stick
clockwise/counterclockwise.
Push the joystick left/right
DVR ID:[255 – 255]
BAUD RATE
or twist the joystick
COMM.:EMBEDDED DVR
2400 BPS
clockwise/counterclockwise.
→BAUD :9600 BPS
4800 BPS
PORT :RS-485
9600 BPS
38400 BPS
