Top View 525AT
Dimensions
30” (76 cm)
1
70.5” (179 cm)2
Choosing and Preparing Site
Before assembling the unit, verify the chosen site meets the following criteria:
• Area is well lit and well ventilated.
• Surface is structurally sound and properly leveled.
• Free area for access to unit and emergency dismount. Minimum clearance is 23.6 inches (0.6 meters).
• Adjacent units may share the free area.
Free Area
23.6”, 0.6m1
It is the responsibility of the facility owner/owner of the equipment to ensure that there is appropriate
clearance around each machine to allow for safe use and passage.
Page 10 of 82
Cybex 525AT Arc Trainer Part Number 5525-4 F
