Assembly Procedure
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base assemblyVaries11
Console assemblyVaries12
Foot pad12090-32223
Base, Accessory tray-14
Cover, Top, Accessory tray770A-31715
Cover, Bottom, Accessory tray770A-31816
Hardware pack525AT-106-417
Owner’s Manual5525-X18
Assembly poster525AT-32819
Consumer Arc warranty sheet525AT-331110
Entry Commercial Arc warranty sheet525AT-330111
Full Commercial Arc warranty sheet525AT-413112
Cable, 6’, Coax (E3 View Monitor option)770A-427113
Page 12 of 82
Cybex 525AT Arc Trainer Part Number 5525-4 F
