Install top cap
Install top cap with two screws using a Phillips screwdriver.
Qty.Description
1Top Cap1
2Screws2
Install back cap
1. Place the back cap into the top cap.
Ensure the back cap is fully inserted into the top cap.
Qty.Description
1Top Cap1
2Screws2
1Back Cap3
2. Install the back cap with two screws using a Phillips screwdriver.
