DescriptionPart NumberQuantityItem
Screw, 5/16-18 x .75”,HXHD,WHIZ-LOCK,GR5HS-19108413
Washer, 5/16” SplitHW-53018414
Screw, 8-16 x .50”, PNHDHS-15706615
Screw, 8-16 x .75”, PNHDHS-18311216
Screw, 5/16-18 X 1.50”HS-41107417
3/16” Allen wrenchHX-00438118
Figure 2: Hardware
Lift and move the unit
1. Grasp the rear foot.
2. Lift the rear foot so the front transport wheels are able to roll on floor.
Use proper lifting methods.
3. Roll unit to intended location.
4. Lower the rear foot so unit is in intended location.
Page 22 of 80
Cybex 525C/525R Cycle Part Number LT-24303-4 E
