CYBEX 525C User Manual

Install seat back assembly
1. Place the seat back assembly in the correct position and hand thread each of the screws and four
washers.
Qty.Description
1Seat Back Assembly1
4Washers2
4Screws3
2. Securely fasten the screws with the 3/16” Allen wrench provided.
Install console assembly
1. Hand thread two mounting screws into the base assembly.
Qty.Description
1Console Assembly1
2Screws2
1Base Assembly3
The console assembly will need to be supported during steps 2 through 4.
Page 23 of 80
Cybex 525C/525R Cycle Part Number LT-24303-4 E
