CYBEX 525C User Manual

8. Connect the console cable’s DIN connector to the power supply output.
Make sure the two connectors snap firmly together and can not be pulled apart without pulling the
sleeve back to release it.
Qty.Description
1Power Supply Output1
1Console Cable DIN Connector2
1Power Cord3
Install front covers
1. Install front right cover with three screws using a Phillips screwdriver.
Qty.Description
3Screw, 8-16 × .50”1
1Screw, 8-16 × .75”2
1Front Right Cover3
In addition to three mounting screws per front cover, there are five plastic connectors that secure
the front covers together. Ensure that all four plastic connectors are inserted properly in each front
cover.
Page 25 of 80
Cybex 525C/525R Cycle Part Number LT-24303-4 E
