Cybex 530C and 530R Owner’s Manual
Explanation of Symbols Used
Safety
Page 1-13
Power adapter port - Diagram shows voltage polarity of plug used in the optional
power adapter. Input 9v/1.7A DC. Use Cybex supplied adapter only.
Class II Equipment - Classifies equipment as Class II with double insulation.
Type BF Applied Part - Classifies equipment as Type BF, providing protection
against electric shock.
CE - The CE (Conformitè Europèenne) mark is a European Union approval indicating
that a product complies with a European Directive.
Pause/End(Stop) - Press once to pause program.
Quick Start - Press to skip Program Setup Mode and enter Manual Mode.
Up Arrow - This key adjusts Time, Level, Weight or RPM up.
Down Arrow - This key adjusts Time, Level, Weight or RPM down.
Level Plus - This key adjusts Level up.
Level Minus - This key adjusts Level down.
DC Power - This symbol is for DC power input.
TV - This symbol is for TV signal and DC power inputs for the A/V option.
Cycle - This symbol is for DC power input for the cycle.
