Cybex 530C and 530R Owner’s Manual
Customer
Service
Page 6-4
2 1 AD-17885 PCA, CONTROLLER, HYBRID BRAKE
5 1 AF-18164 PLATE, POWER JACK COVER
8 1 AD-17886-Q PCA, I/O BOARD
8 1 AD-18456-Q PCA, I/O BOARD, A/V OPTION
9 1 AX-18105 ASSY, IDLER, RIGHT
10 1 AX-18106 ASSY, IDLER, LEFT
11 1 AX-18138 PEDAL SET, X-WIDE, 9/16” THREAD
11 1 HX-18903 PEDAL STRAP, RIGHT
11 1 HX-18904 PEDAL STRAP, LEFT
11 2 HX-18832 PEDAL STRAP, YELLOW, IFI
12 1 AX-18257 ASSY, HANDRAIL, 530C
13 1 AX-18264 ASSY, RIGHT SHROUD, 530C
14 1 AX-18265 ASSY, LEFT SHROUD, 530C
16 1 AX-62023 ASSY, LEFT CRANK BEARING
17 1 AX-62031 ASSY, RIGHT CRANK BEARING
18 1 AX-17693 ASSY, SEAT POST
19 1 AX-17959 CRANK ASSY, 530
20 1 AX-17967 ASSY, SECONDARY PULLEY
21 1 SK-19458 BELT, POLY-V, 380J6, Secondary
22 1 SK-19457 BELT, POLY-V, 430J10, Primary
24 2 CW-50026 WHEEL FRONT MOLDED
26 3 EH-00472 TY WRAP, TY-23M
27 2 FM-51215 SPACER BOTTOM ROLLER SIDE Y-065
28 1 FM-18011 PIN, SEAT ADJUSTING
29 1 FS-18063 PLATE, SEAT POST STOP, FRAME
30 1 FS-18220 COVER, LOWER CONTROLLER, 530C
31 1 FS-18261 PLATE, CONSOLE CABLE CONNECTOR
32 2 HN-11136 KEPS 5/16-18 HEX STL ZINC
33 4 HS-13765 SCREW, 10-32 X 1.0”, SCHD, STL, ZN
34 1 HN-41157 NUT, 7/8-24, LH, 86A, ZN
35 2 HS-11874 BOLT LOCK, 1/4-20 X .75”, G5
37 10 HS-15706 SCREW, 8-16 X .50”, PNHD, STL, BLK ZN C
39 2 HS-15763 BOLT, 1/4-20 X .375”, FLHD, NYLOCK
40 4 HS-18127 BOLT, 1/4-20 X 1.25”, BHCS, SS, BLK
41 1 HS-18157 BOLT, 5/16-18 X 1.25”, BTHD, SS, BLK
42 4 HS-18183 BOLT, 5/16-18 UNC X .75”, SCHD
43 3 HS-18374 SCREW SEMS, 6-32 X .875”, PNHD PHIL, S
44 4 HS-18290 SCREW, SLFTP, 10 X 2.5”, STL, ZN BLK, TY
45 4 HS-18294 SCREW, SEMS,10-32 X .38”, SLOT HXHD
46 8 HS-18311 SCREW, 8-16 X .75”, PNHD PHIL, STL, BLK
47 15 HS-41006 SCREW SLFTP, 10-24 X .5, PNHD PHIL
48 2 HS-41126 BOLT, 5-16 X 1.0”, BTHD, SST, BLK
49 2 HW-43042 WASHER, HDS-8 5/16” (8MM) BELLEVILLE
50 1 HW-18176 WASHER, CRANK KEY
51 2 HW-53017 WSHR FLAT, 5/16”, SS, BO
52 5 HW-53018 WASHER 5/16”, SPLIT SS, BLK
53 4 HW-00180 WSHR LOCK SPLIT, 1/4”, SST, BLK PASS
54 5 HX-14416 CLIP, WIRE LATCHING, 1 X 1”
ITEM QTY PART NO. DESCRIPTION
Parts List Cybex 530C Cybex
