Cybex 530C and 530R Owner’s Manual
2 1 AD-17885 PCA, CONTROLLER, HYBRID BRAKE
3 1 AD-17886-Q PCA, I/O BOARD
3 1 AD-18456-Q PCA, I/O BOARD, A/V OPTION
6 1 AF-18164 PLATE, POWER JACK COVER
7 1 AX-17564 ASSY, SEAT SHUTTLE
8 1 AX-62031 ASSY, RIGHT CRANK BEARING
9 1 AX-18105 ASSY, IDLER, RIGHT
11 1 AX-18138 PEDAL SET, X-WIDE, 9-16” THREAD
11 1 HX-18903 PEDAL STRAP, RIGHT
11 1 HX-18904 PEDAL STRAP, LEFT
11 2 HX-18832 PEDAL STRAP, YELLOW, IFI
12 1 AX-18106 ASSY, IDLER, LEFT
13 1 AX-18262 ASSY, RIGHT SHROUD, 530R
16 1 AX-18263 ASSY, LEFT SHROUD, 530R
18 1 AX-62023 ASSY, LEFT CRANK BEARING
19 1 AX-17959 CRANK ASSY, 530
20 1 AX-17967 ASSY, SECONDARY PULLEY
21 1 SK-19459 BELT, POLY-V, 480J6, Secondary
22 1 SK-19457 BELT, POLY-V, 430J10, Primary
24 2 CW-50026 WHEEL, FRONT, MOLDED
25 1 EC-17877 SENSOR, POLAR WIRELESS REMOTE MOUNT
27 4 FM-51215 SPACER, BOTTOM ROLLER SIDE, Y-065
28 1 FS-18261 PLATE, CONSOLE CABLE CONNECTOR
30 1 FS-18205 COVER, LOWER CONTROLLER, 530R
31 12 HS-15706 SCREW, 8-16 X .50”, PNHD, STL ,BLK ZN
32 4 HN-11136 KEPS, 5/16-18” HEX, STL, ZINC
33 4 HS-13765 SCREW, 10-32 X 1.0”, SCHD, STL, ZN
34 4 HW-00123 WASHER, SAE NO.10, STL, ZINC
35 4 HS-18294 SCREW, SEMS, 10-32 X .38”, SLOT HXHD
36 3 HS-18374 SCREW, SEMS, 6-32 X .875”, PNHD PHIL
37 4 HS-18289 SCREW, SLFTP, #10 X 1.5”, STL, ZN BLK
38 18 HW-53018 WASHER, 5/16”, SPLIT, SS, BLK
40 4 HS-18127 BOLT, 1/4-20 X 1.25”, BHCS, SS, BLK
41 4 HS-18183 BOLT, 5/16-18 UNC X .75”, SCHD
42 1 HN-41157 NUT, 7/8-24”, LH, 86A, ZN
43 4 HW-00180 WASHER, LOCK SPLIT, 1/4”, SST, BLK PASS
44 4 HS-41109 SCREW, SLFTP, 10-24 X .75”, PNHD, SST
45 1 HW-18176 WASHER, CRANK KEY
47 10 HS-41006 SCREW, SLFTP ,10-24 X .5”, PNHD PHIL
48 8 HS-41126 BOLT, 5/16 X 1.0”, BTHD, SST, BLK
49 1 HX-18449 TAPE, DOUBLE SIDED, 1.25 X 1.25 X .03”
51 1 HX-18024 SPRING, EXTENSION, .75” X .115 X 7”, Silver
52 1 HX-18036 SPRING, EXTENSION, .50” X .072 X 6”, Gold
53 4 HX-18133 RETAINING, E-RING, 5133-37
54 5 HX-14416 CLIP, WIRE LATCHING, 1 X 1”
55 1 PL-50118 CLAMP, CABLE CT
56 4 HS-12031 SCREW, SEMS, 10-32 X .62”, PNHD PHIL
58 1 PL-18132 CAP, END, EXTRUSION
ITEM QTY PART NO. DESCRIPTION
Customer
Service
Page 6-7
Parts List Cybex 530R Cybex
