Cybex 530C and 530R Owner’s Manual
Preventive
Maintenance
Page 4-9
! WARNING: The flywheel may be hot. Wait until it cools before servicing.
7. Check the condition of each belt.
A. Rotate each belt by slowly turning pulleys backwards. NOTE: Be careful to not pinch your
fingers between belts and pulleys. Examine the condition of each belt. If a belt has cracks or
appears worn, it must be replaced immediately by a qualified service technician. See Figures
13, 14 and 15.
Good Belt
Figure 13
Figure 15
Wear
Figure 14
Cracks
To Next Page
