CYBEX 530R User Manual

320 4 HS-18311 SCREW, 8-16 X .75”, PNHD PHIL, STL, BLK
340 1 AW-18160 CABLE, CONSOLE HARNESS, 530R
350 1 AW-18365 CABLE, GROUND, UPPER, 530R
363 1 AF-18104 BRKT, SPRING TENSIONER, RIGHT
364 4 HB-18056 BUSHING, FLANGE, .375 X .469 X .25”
365 2 HB-18059 IDLER WHEEL, 1.88 X 1.15”
366 2 HN-42043 NUT, 3/8-16”, FLANGED, SS, BO
367 1 AF-18053 BRACKET, SPRING TENSIONER, LEFT
373 1 FM-54075 RACE, CRANK, LEFT
374 2 HB-44062 BEARING, RADIAL BALL, 30 MM, W-SEALS
375 1 FM-54074 RACE, CRANK, RIGHT
420 1 AF-20726 HANDLE, RECUMBENT IFI
421 1 AF-20719 BRACKET, HANDLE MOUNT, RIGHT, RECUMBENT IFI
422 1 AF-20720 BRACKET, HANDLE MOUNT, LEFT, RECUMBENT IFI
423 1 AF-20727 LEVER, SEAT ADJUSTMENT, RECUMBENT IFI
424 1 AF-20758 WELDMENT, 90 DEG CONNECT, RECUMBENT IFI
425 1 HS-20730 SCREW, SHEILD, 3/8 DIA. X 1.25 X 5/16-18”
426 4 HB-20728 BEARING, FLANGE, NYLON 3/8” DIA. SHAFT
431 2 AX-19669 GRIP, HR TOP, IN-MOLDED
432 2 AX-19670 GRIP, HR BOTTOM, IN-MOLDED
433 2 PL-20230 END CAP, CONTACT GRIP
434 2 HX-18974 SEAL, HR GRIPS
435 4 HS-20306 SCREW, 6-20 X 1.12” PNHD, PHIL
450 1 AF-17552 WELDMENT, SEAT SHUTTLE, 530R
451 1 AF-18000 WELDMENT, SHUTTLE HANDLE
452 1 AX-17578 ASSY, CONTACT GRIP, PAIR
453 4 AX-18148 ASSY, SEAT SHUTTLE WHEEL
454 1 AW-17882 CABLE, CHR GRIPS, 530R
456 2 CW-18141 WHEEL, LOWER RIGHT, TAPERED
457 2 CW-18144 WHEEL, LOWER LEFT, BEVELED
458 4 FM-18143 SPACER, LOWER SHUTTLE WHEEL
459 4 FS-18023 PLATE, WHEEL TENSION ADJUSTER
460 2 HB-18121 BUSHING, FLANGED, PLASTIC, 5/16 ID”
461 2 HN-11925 KEPS, 10-32, HEX, STL, ZN
462 4 HN-18252 NUT, 5/16-18”, PREVAILING TORQUE
463 1 HN-60558 NUT, NYLOC, .250-20, ZN, BLK
464 1 HS-18497 SCREW, 10-32 x .50”, PNHD PHIL, BLK ZN
465 4 HS-18298 BOLT, 5/16-18 X .88”, BTHD CAP, SS, BL
466 1 HS-18089 BOLT, SHEILD, 5/16 X 2.75”, SCHD
467 8 HS-18358 BOLT, 5/16-18 X .1.25”, SCHD CAP, BLK
468 8 HW-18123 WASHER, .344 ID X .75 OD X .125”, THICK
472 1 HX-18168 SPRING, TORSION, SEAT SHUTTLE
473 1 PD-18166 SEAT, BOTTOM, 530R
474 1 PL-18122 ACCESSORY TRAY, 530R
475 1 PL-18204 CLAMP, FLAT CABLE COVER
477 1 DE-18288 LABEL, EXTRUSION
478 1 FM-18085 EXTRUSION, SEAT SHUTTLE
480 1 FS-18124 BRACKET, SEAT ADJUST RACK
482 2 HX-05082 BUMPER, SEAT LIMIT, BMR R-035
484 2 HS-41048 BOLT, 5/16-18 X 2”, BTHD CAP, BLK OX
486 4 CA-40052 CAP, PLASTIC, 1 X 1”, 10-14 GA.
487 2 FT-18080 TUBE, SEAT BACK, POWDER COATED
ITEM QTY PART NO. DESCRIPTION
Customer
Service
Page 6-9
Cybex 530C and 530R Owner’s Manual
