Be careful not to spill or get excessive moisture between the edge of the display panel and the console,
as this might create an electrical hazard or cause failure of the electronics.
As Needed
Vacuum any dust or dirt that might accumulate under or around the unit. Cleaning this area should be
done as often as indicated in the Service Schedule.
Clean Console
Do not spray cleaning solution directly on the console. Direct spraying could
cause damage to the electronics and may void the warranty.
• Spray a mild cleaning agent on a clean cloth.
• Clean the console, accessory tray, and cup holder with a damp cloth.
Clean Base
• Spray a mild cleaning agent on a clean cloth.
• Clean the base of the unit with a damp cloth.
Contact Heart Rate Grips
Clean the grips using a cloth dampened with a cleaning solution containing rubbing alcohol.
Contaminants, such as hand lotions, oils or body powder, may come off on the contact heart rate grips.
These can reduce sensitivity and interfere with the heart rate signal. It is recommended that the user
have clean hands when using the contact heart rate.
Vacuum Motor Bay
Tools Required
• Phillips screwdriver
• Clean Cloth
• Vacuum, with tip for small spaces
1. Loosen but do not remove the two front cover screws securing the motor cover using a Phillips
screwdriver.
2. Lift the cover straight up; the screws will stay in place.
3. Vacuum the exposed elevation assembly, drive motor, lower electronics and the surrounding areas.
Page 65 of 88
Cybex 625T Treadmill Part Number LT-23221-4 H
