Cybex 750C/750R Owner’s Manual
Assembly and Setup
Page 2–4
Item Qty Part Number Description
11 4 HS-19108 Screw, 5/16-18 x .75”,HXHD,WHIZ-LOCK,GR5
12 6 HS-15706 Screw, 8-16 x .50”, PNHD
Figure 1b
Hardware
#11#7
#2
#4
#11
#12
#12
#5
#1
#12
#3
#12
#6
#12
WARNING: Always use proper lifting methods when moving heavy items.
2. Lift and move the unit
A. Firmly grasp the rear foot.
B. Using proper lifting methods, lift the rear foot so the front transport wheels are able to roll on
floor.
C. Move or roll unit to intended location.
