Operation
Page 3–5
Cybex 750C/750R Owner’s Manual
Audio Visual (AV) Key Pad – Optional
Console Key Description
EPG If an Electronic Program Guide (EPG) is available, this will be displayed on
the TV. Use the CHANNEL Λ V and VOLUME < > keys to navigate in the
EPG, ENTER to accept any selections, and CLEAR/EXIT to exit the EPG
mode.
CHANNEL Toggle down or up to change channel (beeping will occur).
VOLUME Press appropriate keys to increase or decrease volume. There is no display
interaction.
VIDEO SOURCE Press to toggle between video source A for cable channels and video
source B for external inputs, such as iPod
®
video.
VIDEO PORT Video capable port allows personal entertainment device or other
composite video input.
USB PORT Universal Serial Bus (USB) allows different devices to be connected using a
single standardized interface port for charging only.
HEAD PHONE PORT
Head phone port allows personal headphones.
Figure 2
1 – Video 3 – Left
2 – Ground 4 – Right
