CYG PRS-7910 User Manual

PRS-7910
40 PRS-7910
Log
S32
QueryLogByTime
O
N
S33
QueryLogAfter
O
N
S34
GetLogStatusValues
O
N
Generic substation event model (GSE)
GOOSE control block
S35
SendGOOSEMessage
M
Y
S36
GetGoReference
O
Y
S37
GetGOOSEElementNumber
O
N
S38
GetGoCBValues
M
Y
S39
SetGoCBValuess
M
N
Control
S51
Select
O
N
S52
SelectWithValue
M
Y
S53
Cancel
M
Y
S54
Operate
M
Y
S55
Command-Termination
O
Y
S56
TimeActivated-Operate
O
N
File transfer
S57
GetFile
M/O
Y
S58
SetFile
O
N
S59
DeleteFile
O
N
S60
GetFileAttributeValues
M/O
Y
Time
SNTP
M
Y
9.4.7 Logical Nodes
9.4.7.1 Logical Nodes Table
The PRS-7910 series relays support IEC61850 logical nodes as indicated in the following table.
Note that the actual instantiation of each logical node is determined by the product order code.
9.5 DNP3.0 Interface
9.5.1 Overview
The descriptions given here are intended to accompany this relay. The DNP3.0 protocol is not
described here; please refer to the DNP3.0 protocol standard for the details about the DNP3.0
implementation. This manual only specifies which objects, variations and qualifiers are supported
in this relay, and also specifies what data is available from this relay via DNP3.0.
The relay operates as a DNP3.0 slave and supports subset level 3 of the protocol, plus some of
the features from level 4. The DNP3.0 communication uses the Ethernet ports (electrical or optical)
at the rear side of this relay.
