PRS-7910
12 PRS-7910
5 Management
5.1 Real Time Data Interrogation
This device can display the IO status, measurement & metering values, settings & parameters of
the device itself and connected lEDs by the means of network interrogation.
5.1.1 IO Status
Main Menu"-> "Database"->"Online"->"Status"
The status of binary inputs, output contacts, device alarms and network communication
connection states can be interrogated and viewed in this category.
5.1.2 Measurement
"MainMenu"-> "Database"->"Online"->"Measmt"
The measured values, including both AC & DC analog inputs, can be interrogated and viewed in
this category.
5.1.3 Tap Position
"MainMenu"-> "Database"->"Online"->"TP"
The transduced tap positions can be interrogated and viewed in this category.
5.1.4 Metering
"MainMenu"-> "Database"->"Online"->"Metering"
The counted metering values can be interrogated and viewed in this category.
5.1.5 IED Parameter
"MainMenu"-> "Database"->"Online"->"Grp No."
The setting group (especially for a protection relay) can be interrogated and viewed in this
category.
5.1.6 Setting Group
"MainMenu"-> "Database"->"Online"->"Grp No."
The setting group (especially for a protection relay) can be interrogated and viewed in this
category.
5.1.7 IED Setting
"MainMenu"-> "Database"->"Online"->"IED setting"
The settings can be interrogated and viewed in this category.
5.2 Event Recording
The device can store enormous SOE (Sequence of Events) records and device logs of this device
itself and all the connected IED in its inner integrated history database. All the records are stored
