CZone Touch 7 - 5 Specifications; 5.1 Technical Specifications; 5.2 Physical Dimensions

21
EN / CZone® Touch 7 User & Installation Manual
5 SPECIFICATIONS
Technical Specifications
Model
Touch 7
Article number
80-911-0200-00
Display Size
7.0 Inch
Resolution
1024 x 600 pixels
Brightness
550 cd/m²
Colours
24-bit RGB
Touch Screen
Projected Capacitive
CPU
NXP/Freescale i.MX6DL Dual-Cortex A9
Operating Voltage
8-32V DC
Current Draw Operating
430mA @ 12V (backlight 100%)
Current Draw Standby
130mA @ 12V (backlight off)
Operating Temperature
-20°C to 70°C (-4°F to 158°F)
Storage Temperature
-40°C to 85°C (-40°F to 185°F)
Ingress Protection
None, IPX0
Interfaces
USB2.0, Ethernet, NMEA2000, WiFi
Weight (excluding mounting
hardware)
695 grams (1.53 lbs)
DC Power Connector Part #
Phoenix 1777992 MSTB 2,5/ 3-STF-5,08
Certification
CE, FCC, RCM
Warranty Period
2 Years
Dimensions
Figure 13. Dimensions
